# 6.14. Equation Editor

## Equation Editor

Add graphical, MathML, and LaTeX equations to your content using the Graphical Equation Editor. The Equation Editor is available within the Brightspace Text/HTML Editor. Using this feature allows users to insert mathematical and statistical equations into their content in the Brightspace platform tools that have HTML content creation capabilities, such as discussion topics, custom instructions for assignment folders, content topics, and more.

**Graphical Editor**

The Graphical Editor features a toolbar equipped with a selection of tool buttons. This toolbar provides the necessary elements to construct your equations quickly and easily. Each button in the Equation Editor toolbar opens a palette of related mathematical symbols. This editor is the most visual of the three options and it is best suited for those that only write equations occasionally.

**LaTeX**

LaTeX is a typesetting system based on TeX. Although there’s a bit of a learning curve, it’s compact and efficient once you’re familiar with the commands. Advanced users find that this is the fastest input type.

There are two possible modes for LaTeX entry: text mode and math mode. MathJax supports math mode only. If you add LaTeX using the Equation Editor, allow for the following differences in math mode:

- Most spaces and line breaks are not recognized and have to be specified with special commands such as \quad.
- Empty lines are ignored, only one paragraph per formula.
- Each letter is considered to be the name of a variable and will be typeset as such. If you want normal text within a formula (normal upright font and normal spacing) then you have to enter the text using dedicated commands.

**MathML**

MathML is a standard adopted by the World Wide Web Consortium (W3C). It uses XML to describe mathematical notation by capturing both its structure and content. This enables MathML to support the visual display and assistive technology access.

Its appearance is similar in structure to HTML. Unlike HTML, MathML is not designed to be hand-written. It is recommended that you compose equations in a visual editor and paste its MathML output into the Brightspace Equation Editor.
