Using Graphs to Solve Equations

Using and creating graphs to solve quadratics and pairs of simultaneous equations.
  Menu   Level 1 Level 2 Level 3 Level 4 Exam-style   Help     More

For this level you will draw graphs on graph paper using a very sharp pencil and nice ruler.

TI-nSpire

If you don't have graph paper you can print a sheet from this Graph Paper page.

Take a full, fresh sheet of graph paper and place it on a clear desk, in a good light portrait way round.

Using a scale of 2cm to represent one unit draw an x-axis from -4 to 4
Add a y-axis from -8 to 5

Draw accurate graphs then use them to find a solution to the following simultaneous equations:

\( \quad \quad y=x-4\)
\( \quad \quad y=1-x\)

\(x =\) ☐ ✓ ✗ ☐\(y =\) ☐ ✓ ✗

3

Using a scale of 2cm to represent one unit draw an x-axis from -2 to 4
Add a y-axis from -5 to 5

Draw accurate graphs then use them to find the largest value of \(x\) which is a solution to these simultaneous equations:

\( \quad \quad 2y=x+2\)
\( \quad \quad y=x^2-2x-3\)

Type in the answer correct to one decimal place:

☐\(x =\) ☐ ✓ ✗

4

Using a scale of 4cm to represent one unit draw an x-axis from 0 to 3
Add a y-axis from 0 to 3

Draw accurate graphs within the scope of these axes to find a value of \(x\) which is a solution to these simultaneous equations:

\( \quad \quad y=x^2+3x-4\)
\( \quad \quad y=2-(x-1)^2\)

Type in the answer correct to one decimal place:

☐\(x =\) ☐ ✓ ✗

5

Using a suitable scale (to make the graphs as large as possible) draw an x-axis from -2 to 2
Add a y-axis from -2 to 2

Draw accurate graphs within the scope of these axes to find the largest value of \(y\) which is a solution to these simultaneous equations:

\( \quad \quad y=x^3-2x-1\)
\( \quad \quad y=2^x - 2\)

Type in the answer correct to one decimal place:

☐\(y =\) ☐ ✓ ✗

6

The graphs of the following equations intersect in the region \(0 \le x \le 4\):

\( \quad \quad y=x^3-3x^2\)
\( \quad \quad y=\frac{1}{x+5}\)

By drawing graphs (choose your own scale for each of the axes) find the value of \(x\) at the point where this intersection occurs correct to one decimal place:

☐\(x =\) ☐ ✓ ✗

Check

This is Using Graphs to Solve Equations level 3. You can also try:
Level 1 Level 2 Level 4
